Descripción
With a power consumption of 1,300 W, the power package drives up to 23,000 liters of dirty water per hour. The high-value double sliding ring seal provides long service life and extensive maintenance freedom. The upper and lower casing as well as the cast pump wheel of the GC-DP 1340 G are made of cast steel, the suction casing and motor casing are made of corrosion-resistant stainless steel.
Its infinitely height-adjustable float switch allows selection between permanent operation and a preselected on/off level. The G2 hose connection is designed for 2" hoses (approx. 50.8 mm). A practical carrying handle enables convenient transportation of the waste water pump. A cable with a length of of 6 meters for purging the pump in the tank / well.
CHARACTERISTICS
- Carrying handle
- Steplessly height-adjustable float switch
- Double slip ring seal for long life
- Upper + lower casing part made of cast iron, stainless steel suction / motor casing
- Casting pump wheel
- Incl. 6 meters of cable
- Pipe connection for approx. 50.8mm (2")
SPECIFICATIONS
- Mains supply: 230 V 50 Hz
- Power: 1300W
- Max. delivery capacity: 23000 L/h
- Max. delivery height: 10 m
- Max. immersion depth: 5 m
- Max. temperature of water: 35 °C
- Max size of foreign particles: 40 mm
- hose connection: 59.6 mm - 2" (thread)
- Power cable: 10 m H07RN-F
